Auto Reparing Car Body Filler

FOB Reference Price:Get Latest Price
$1.00 - $7.00 / Liter | 1000 Liter/Liters (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Guangdong, China
Brand Name:
DOXU
Model Number:
DX627J
CAS No.:
123-86-4
Other Names:
CAR REFINISH
MF:
Customized
EINECS No.:
Customized
State:
Liquid Coating
Main Raw Material:
Acrylic
Usage:
Appliance Paint, Car Paint, Electrical Insulating Varnish, Plastic Coating
Application Method:
Spray
Function:
Chemicals, Coating&Paint , Car Paint, Filling Primer
Chemical Composition:
Modified Acrylic Resin
Spraying Viscosity:
15 - 18s/23℃
Color:
Light Grey
Packaging:
4 kg/Can
Film Thickness:
35-45μm
Certificate:
SGS, ISO14000, ISO9001
Product Process:
Automated machinery
Supply Ability
Supply Ability:
5000 Metric Ton/Metric Tons per Year
Packaging & Delivery
Packaging Details
1L*12Can/Box; 4L*6Can/Box;5L*4Can/Box; 18L/Can
Port
Huangpu/ Nansha, Guangzhou
Product Description






Product Name:  Auto Filling & Reparing Car Body Filler   ( DX627J)



Product Description:

DX-627 is 1K fast drying paint, which usually use for the primer complementary. It has good

workability, fast drying property and can also support the primer to achieve excellent sickness

& make the sanding easier & faster.



Product & Auxiliary:

Doxu 1K Primer DX-627

1K Thinner DX-300 Series(DX-300 fast drying, DX-300 standard, DX300 slow drying)



Chemical Composition:

Doxu 1K Primer[DX-627]: Modified Acrylic Resin



Surface of Application:

Epoxy Primer[DX-623]

Poly putty[DX-628]

Intact old paint



Surface Preparation:

To remove the grease and paraffin by degreaser before polishing,

Prepare 2pcs of cleaned clothes, one for wiping the degreaser and the other is for removing the grease

To process the original paint by dry polish the substrate with 320-400 grits sanding paper,

or wet polish it with 800-1000 grits sanding paper

Poly Putty[DX-628] to dry polish it with 400grit sanding paper.



Mixing Ratio(Volume):

100 portion: 1K primer [DX-627]

80-100 portion: 1K Thinner DX-300 series

To mix the above material evenly in a certain container before using.



Spraying Gun, Nozzle, Spraying Pressure:

Spraying Gun, Nozzle, Spraying Pressure

Spraying Gun, Nozzle(mm)

Spraying Pressure {bar}

Gravity

1.8-2.0

2-4bar

Suction

1.8

2-4bar

HVLP

1.2-1.5

0.7bar

Pressure

1.1-1.24-6bar

Vacuum

1.2-0.011 Inches/65°140-160bar



Spraying Method:

To spray 2-3 layers, curing time between each layer should normally be 3-5min till the former layer is dry and

appear to be matt. The interval of each layer is affected a lot by the temperatureand airflow condition.



Drying time:

Drying time20℃60℃

Tack-free

5min2min

Sanding

1.5hrs30min





Drying & Curing time:



Curing agent

20 ℃

3560

Dust-free

15min10min5min

Tack-free

30min

20min10min

Assembling

20hrs12hrs45min

Polishing

10hrs6hrs50min



















The curing time above is just refer to the match with 2K finish coat, the specific drying & curing time for the match of different finish coat would be various



Recommended Sanding Paper :

MethodsGrits
Wet polishing, Manual

800- 1000#

Dry Polishing. Automatic

320- 400#



Packaging :

1L/4L Can





Storage Period:

Can be stored for 2 years in its sealed original drums in proper storage conditions.

Can be stored for 2 years in its sealed original drums in proper storage conditions.
